Compatible with an assortment of batteries, including Lithium, the Rover Elite MPPT utilizes powerfully smart tracking technology to maximize solar charging energy to your battery. Additionally, the Rover Elite MPPT is equipped with multiple battery, controller, and solar protections giving you peace of mind and an optimized system you can trust.
Please Note: The Rover Elite is not compatible with the Renogy BT-1, only compatible with BT-2 Bluetooth module.
| ROVER ELITE 20A MPPT SOLAR CHARGE CONTROLLER | |
|---|---|
| System Voltage: 12V/24V Auto Recognition | Battery Rated Current: 20A |
| Max Power Input: 12V @ 260W; 24V @ 520W | PV Input Voltage Range : 15V – 100V VOC |
| Max Battery Voltage: 32V | Self Consumption: ≤0.6W @12V£»≤0.8W @24V |
| Temperature Compensation: -3mV/℃/2V, excludes LI | Operating Temperature: -35°C~ 65°C / -31°F ~ 113°F |
| Storage Temperature: -40°C~ 80°C / -40°F ~ 176°F | Operating/Storage Humidity: < 90%, No Condensation |
| Dimensions: 161.5 x 97.9 x 66.5 mm/ 6.36 x 3.85 x 2.62 in | Weight: 0.75 kg/1.65 lbs |
| Enclosure: IP32 | Communication: RS485 |
| Grounding Type: Negative | Controller Terminals: 20-6 AWG |
